High voltage lab

A key facility within the engineering precinct, Deakin's High voltage lab dazzles visitors with tangible lightning bolts. The lab provides electrical engineering students and industry partners a safe and controlled environment to conduct electrical-related experiments.

Test electrical-related experiments

Located at our Geelong Waurn Ponds Campus, the High voltage lab is used by students studying the Bachelor of Electrical and Electronics Engineering, final-year project students, research students and academic staff. Deakin invested over $1 million setting up the lab, making it one of only a few of its kind in Australasia.

Use our Tesla transformers

Students, researchers and industry can utilise a number of Tesla transformers within the lab to test electrical-related experiments. Examples of tests that are possible include: measuring of breakdown voltage of materials, testing the effect of pollution and contaminants on resistors (dust, dirt, salt), and examining the design of insulators used in high-voltage areas.

Deakin's High voltage lab in action

Deakin's High voltage lab in action

One of our more popular pieces of equipment, our Two 1mV DRSSTC Tesla coils are used to generate lightning-like shows for guests, tour groups and outreach activities. It provides a unique opportunity to safely make electrical observations up close.

Study with us

When you study engineering at Deakin you get real-world experience via project-oriented design-based learning. You'll undertake team-based projects and develop solutions to current industry needs, so you can hit the ground running when you graduate.

Lab equipment and technology

The High voltage lab is completely shielded from electromagnetic forces, making it a useful area to test radio frequency devices. In addition, the lab includes a wide suite of electrical testing equipment including:

Terco high voltage DC rig

Capable of generating direct current (DC) voltages up to 480kV at a sustained current of 8mA, the high voltage DC rig is used for voltage withstand tests and observation of corona effects.

Terco high voltage AC rig

The high voltage AC rig can generate alternating current (AC) voltages up to 120kV with a continuous current of 25mA. This can also be configured to perform impulse voltage tests up to 50kV DC with a 1.5/50uS wave shape.

Pressure/vacuum test chamber

The pressure/vacuum test chamber is used primarily to observe effects of pressure variations on electrical discharges. It can also be used to investigate the electrical characteristics of gasses such as SF6 at high voltages.

Industry partners

Our partners are valued members of the wider Deakin engineering family, not just our school. Opportunities to partner with us include work-integrated learning and industry-based learning and placements, student projects, commercial research projects and services.

Partner with us

Contact us

If you have further questions about our High voltage lab, please get in touch.

Email the School of Engineering
